Bashea Smart Series Sumps
Bashsea spares no expense and cuts no corners when it comes to their series of sumps. All Bashsea sumps are CNC and laser machined using a 2-step proprietorial welding process right here in the USA. Utilizing a combination of 1/4" and 3/8", 100% ultra grade, all-American cast acrylic, these sumps are built to last and will make you want to remove the cabinet doors to show how great your system looks.
The only triton-based sump in the industry that allows you to use the triton method ( refugium first) or traditional method (skimmer first.) by utilizing the duel slide control system and Smart baffle design!�
The smart Series allows the end-user to control the filtration flow and method being used completely� The theory behind the smart series design is the hobbyist can change his or her mind on what filtration they want to use but will never need to change sumps! You don't want to miss out on this excellent craftsmanship.� Bashsea once again is bringing a spectacular sump to the industry, sparing no expense and cutting no corners when it comes to their line sumps.�All Bashsea sumps are CNC and laser machined using a 2-step proprietorial welding process right here in the USA. Utilizing a combination of 1/4" and 3/8", 100% ultra grade, all-American cast acrylic, these sumps are built to last and�will make you want to remove the cabinet doors to show how jaw-dropping your system looks now.�
Two sets of down tubes-- one short set if socks are being used and a longer set if the triton method is being used or you're not using the socks
�
The trim around the top of the sump has trimmed cutouts all around to help organize all those cords from equipment, as well as holes for dosing tubes�no more over-tightening those screws down on your probes either. �The Bashsea Smart Series also comes with a 4 probe holder with non-slip grommets.
All Smart Series Sumps sections are fully adjustable with a built-in slide and include Matala baffling material before the pump area for added biological value, micro bubble management and to keep algae and debris from getting into the pump area!
All Smart Series sumps include Bashsea Nylon 200 micron sock. �Socks are located in the front of the sump for easy maintenance and complete viewing control and operation overview.
Smart Series Sumps
SMS-3015
Manufacturer Bashsea
Product Line Smart Series Sumps
Product SMS-3015
Universal Product Code-
Available Styles Blue Grey, Red Grey, White Grey, Black Grey
Physical Properties
Dimensions (L x W x H) 30 x 15 x 16 in 76.2 x 38.1 x 40.64 cm
Weight 30 lb 13.61 k g
Physical Properties (with packaging)
Dimensions (L x W x H) 34 x 19 x 20 in 86.36 x 48.26 x 50.8 cm
Weight 34 lb 15.42 k g
Acrylic Thickness
Top .25 in .64 cm
Sides .25 in .64 cm
Baffles .25 in .64 cm
Bottom .25 in .64 cm
Properties
Cord Control 5
Probe Holders 1
Drains 3 @ diameter of 1 in (2.54 cm)
Socks 3 @ diameter of 4 in (10.16 cm)
Dosing Inputs 3 groups of 4 @ diameter of .3 in (.76 cm)
Sump Section 1
Dimensions (L x W) 13 x 14.5 in 33.02 x 36.83 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 14 in 35.56 cm
Sump Section 2
Dimensions (L x W) 10 x 14.5 in 25.4 x 36.83 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 9 in 22.86 cm
Sump Section 3
Dimensions (L x W) 6.5 x 8.5 in 16.51 x 21.59 cm
Adjustable Gate No
Min Water Height-
Max Water Height-
SMS-3018
Manufacturer Bashsea
Product Line Smart Series Sumps
Product SMS-3018
Universal Product Code-
Available Styles Blue Grey, Red Grey, White Grey, Black Grey
Physical Properties
Dimensions (L x W x H) 30 x 18 x 16 in 76.2 x 45.72 x 40.64 cm
Weight 34 lb 15.42 k g
Physical Properties (with packaging)
Dimensions (L x W x H) 34 x 22 x 20 in 86.36 x 55.88 x 50.8 cm
Weight 38 lb 17.24 k g
Acrylic Thickness
Top .25 in .64 cm
Sides .25 in .64 cm
Baffles .25 in .64 cm
Bottom .25 in .64 cm
Properties
Cord Control 5
Probe Holders 1
Drains 3 @ diameter of 1 in (2.54 cm)
Socks 3 @ diameter of 4 in (10.16 cm)
Dosing Inputs 3 groups of 4 @ diameter of .3 in (.76 cm)
Sump Section 1
Dimensions (L x W) 17.5 x 13 in 44.45 x 33.02 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 14 in 35.56 cm
Sump Section 2
Dimensions (L x W) 17.5 x 10 in 44.45 x 25.4 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 9 in 22.86 cm
Sump Section 3
Dimensions (L x W) 11 x 6.5 in 27.94 x 16.51 cm
Adjustable Gate No
Min Water Height-
Max Water Height-
SMS-316
Manufacturer Bashsea
Product Line Smart Series Sumps
Product SMS-3615
Universal Product Code-
Available Styles Blue Grey, Red Grey, White Grey, Black Grey
Physical Properties
Dimensions (L x W x H) 36 x 15 x 16 in 91.44 x 38.1 x 40.64 cm
Weight 37 lb 16.78 k g
Physical Properties (with packaging)
Dimensions (L x W x H) 40 x 19 x 20 in 101.6 x 48.26 x 50.8 cm
Weight 40 lb 18.14 k g
Acrylic Thickness
Top .25 in .64 cm
Sides .25 in .64 cm
Baffles .25 in .64 cm
Bottom .25 in .64 cm
Properties
Cord Control 5
Probe Holders 1
Drains 3 @ diameter of 1.5 in (3.81 cm)
Socks 3 @ diameter of 4 in (10.16 cm)
Dosing Inputs 3 groups of 4 @ diameter of .3 in (.76 cm)
Sump Section 1
Dimensions (L x W) 17 x 14.5 in 43.18 x 36.83 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 14 in 35.56 cm
Sump Section 2
Dimensions (L x W) 14.5 x 12 in 36.83 x 30.48 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 9 in 22.86 cm
Sump Section 3
Dimensions (L x W) 6.5 x 8.5 in 16.51 x 21.59 cm
Adjustable Gate No
Min Water Height-
Max Water Height-
SMS-3618
Manufacturer Bashsea
Product Line Smart Series Sumps
Product SMS-3618
Universal Product Code-
Available Styles Blue Grey, Red Grey, White Grey, Black Grey
Physical Properties
Dimensions (L x W x H) 36 x 18 x 16 in 91.44 x 45.72 x 40.64 cm
Weight 41 lb 18.6 k g
Physical Properties (with packaging)
Dimensions (L x W x H) 40 x 22 x 20 in 101.6 x 55.88 x 50.8 cm
Weight 46 lb 20.87 k g
Acrylic Thickness
Top .25 in .64 cm
Sides .25 in .64 cm
Baffles .25 in .64 cm
Bottom .25 in .64 cm
Properties
Cord Control 5
Probe Holders 1
Drains 3 @ diameter of 1.5 in (3.81 cm)
Socks 3 @ diameter of 4 in (10.16 cm)
Dosing Inputs 3 groups of 4 @ diameter of .3 in (.76 cm)
Sump Section 1
Dimensions (L x W) 17 x 17.5 in 43.18 x 44.45 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 14 in 35.56 cm
Sump Section 2
Dimensions (L x W) 12 x 17.5 in 30.48 x 44.45 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 9 in 22.86 cm
Sump Section 3
Dimensions (L x W) 6.5 x 11 in 16.51 x 27.94 cm
Adjustable Gate No
Min Water Height-
Max Water Height-Product Data Sheet
V-2023-04-26
SMS-4815
Manufacturer Bashsea
Product Line Smart Series Sumps
Product SMS-4815
Universal Product Code-
Available Styles Blue Grey, Red Grey, White Grey, Black Grey
Physical Properties
Dimensions (L x W x H) 48 x 15 x 16 in 121.92 x 38.1 x 40.64 cm
Weight 45 lb 20.41 k g
Physical Properties (with packaging)
Dimensions (L x W x H) 52 x 19 x 20 in 132.08 x 48.26 x 50.8 cm
Weight 49 lb 22.23 k g
Acrylic Thickness
Top .25 in .64 cm
Sides .25 in .64 cm
Baffles .25 in .64 cm
Bottom .25 in .64 cm
Properties
Cord Control 5
Probe Holders 1
Drains 3 @ diameter of 1.5 in (3.81 cm)
Socks 3 @ diameter of 4 in (10.16 cm)
Dosing Inputs 3 groups of 4 @ diameter of .3 in (.76 cm)
Sump Section 1
Dimensions (L x W) 24 x 14.5 in 60.96 x 36.83 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 14 in 35.56 cm
Sump Section 2
Dimensions (L x W) 16.5 x 14.5 in 41.91 x 36.83 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 9 in 22.86 cm
Sump Section 3
Dimensions (L x W) 6.5 x 8.5 in 16.51 x 21.59 cm
Adjustable Gate No
Min Water Height-
Max Water Height-
SMS-4818
Manufacturer Bashsea
Product Line Smart Series Sumps
Product SMS-4818
Universal Product Code-
Available Styles Blue Grey, Red Grey, White Grey, Black Grey
Physical Properties
Dimensions (L x W x H) 48 x 18 x 16 in 121.92 x 45.72 x 40.64 cm
Weight 50 lb 22.68 k g
Physical Properties (with packaging)
Dimensions (L x W x H) 52 x 22 x 20 in 132.08 x 55.88 x 50.8 cm
Weight 55 lb 24.95 k g
Acrylic Thickness
Top .25 in .64 cm
Sides .25 in .64 cm
Baffles .25 in .64 cm
Bottom .25 in .64 cm
Properties
Cord Control 5
Probe Holders 1
Drains 3 @ diameter of 1.5 in (3.81 cm)
Socks 3 @ diameter of 4 in (10.16 cm)
Dosing Inputs 3 groups of 4 @ diameter of .3 in (.76 cm)
Sump Section 1
Dimensions (L x W) 24 x 17.5 in 60.96 x 44.45 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 14 in 35.56 cm
Sump Section 2
Dimensions (L x W) 17.5 x 16.5 in 44.45 x 41.91 cm
Adjustable Gate Yes
Min Water Height 5 in 12.7 cm
Max Water Height 9 in 22.86 cm
Sump Section 3
Dimensions (L x W) 11 x 6.5 in 27.94 x 16.51 cm
Adjustable Gate No
Min Water Height-
Max Water Height-
|
|
